WT-ME MITSUBISHI SERIES SPECIFICATION 50HZ @ 1500RPM | |||||||||||
Genset Model | 50HZ PF=0.8 400/230V 3Phase 4Wire | Engine Model | cyl | displacement | Battery Vol. | Max power | Governor | Open Type Dimension | |||
Standby Power | Prime Power | Cons 100%(L/H) | |||||||||
KVA/KW | KVA/KW | L | V | KW | L×W×H(MM) | Weight KG | |||||
WT-MEZ688 | 688/550 | 625/500 | 138 | S6R2-PTA-C | 6L | 30 | 24 | 635 | Elec. | 3560*1410*1933 | 5210 |
WT-MEZ730 | 730/584 | 662.5/530 | 138 | S6R2-PTA-C | 6L | 30 | 24 | 635 | Elec. | 3560*1410*1933 | 5210 |
WT-MEZ770 | 770/616 | 700/560 | 163 | S6R2-PTAA-C | 6L | 29.96 | 24 | 710 | Elec. | 3870*1675*2134 | 5021 |
WT-MEZ825 | 825/660 | 750/600 | 163 | S6R2-PTAA-C | 6L | 29.96 | 24 | 710 | Elec. | 3870*1675*2134 | 5021 |
WT-MEZ1375 | 1375/1100 | 1250/1000 | 266 | S12R-PTA-C | 12V | 49.03 | 24 | 1190 | Elec. | 4540*1795*2510 | 9248 |
WT-MEZ1500 | 1500/1200 | 1375/1100 | 281 | S12R-PTA2-C | 12V | 49.03 | 24 | 1285 | Elec. | 4585*2083*2537 | 9953 |
WT-MEZ1650 | 1650/1320 | 1500/1200 | 308 | S12R-PTAA2-C | 12V | 49.03 | 24 | 1404 | Elec. | 4915*2202*2723 | 10613 |
WT-MEZ1850 | 1850/1480 | 1650/1320 | 310 | S16R-PTA-C | 16V | 65.37 | 24 | 1590 | Elec. | 5211*1857*2700 | 11591 |
WT-MEZ1875 | 1875/1500 | 1700/1360 | 310 | S16R-PTA-C | 16V | 65.37 | 24 | 1590 | Elec. | 5211*1857*2700 | 11591 |
WT-MEZ2050 | 2050/1640 | 1860/1488 | 418 | S16R-PTA2-C | 16V | 65.37 | 24 | 1760 | Elec. | 5311*2590*2978 | 12258 |
WT-MEZ2200 | 2200/1760 | 2000/1600 | 432 | S16R-PTAA2-C | 16V | 65.37 | 24 | 1895 | Elec. | 5689*2202*2723 | 12833 |
WT-MEE315 | 315/252 | 288/230 | 66 | S6B-PTA2 | 6L | 12.88 | 24 | 291 | Elec. | 3180*1350*1770 | 2858 |
WT-ME400 | 400/320 | 365/292 | 81 | S6B3-PTA | 6L | 14.6 | 24 | 360 | Elec. | 3180*1350*1770 | 3196 |
WT-ME485 | 485/388 | 440/352 | 97 | S6A3-PTA | 6L | 18.6 | 24 | 430 | Elec. | 3530*1350*1850 | 3863 |
WT-ME688 | 688/550 | 625/500 | 138 | S6R2-PTA | 6L | 30 | 24 | 635 | Elec. | 3600*1520*2140 | 5122 |
WT-ME720 | 720/576 | 655/524 | 138 | S6R2-PTA | 6L | 30 | 24 | 635 | Elec. | 3600*1520*2140 | 5122 |
WT-ME810 | 810/648 | 735/588 | 158 | S12A2-PTA | 12V | 33.9 | 24 | 724 | Elec. | 4050*1630*2080 | 6370 |
WT-ME1100 | 1100/880 | 1000/800 | 227 | S12H-PTA | 12V | 37.1 | 24 | 980 | Elec. | 4330*1760*2380 | 8358 |
WT-ME1375 | 1375/1100 | 1250/1000 | 266 | S12R-PTA | 12V | 49 | 24 | 1190 | Elec. | 4560*2250*2380 | 9435 |
WT-ME1485 | 1485/1188 | 1350/1080 | 281 | S12R-PTA2 | 12V | 49 | 24 | 1285 | Elec. | 4560*2250*2380 | 9548 |
WT-ME1625 | 1625/1300 | 1475/1180 | 308 | S12R-PTAA2 | 12V | 49 | 24 | 1404 | Elec. | 5030*2230*2550 | 10835 |
WT-ME1815 | 1815/1452 | 1650/1320 | 310 | S16R-PTA | 16V | 65.4 | 24 | 1590 | Elec. | 5450*2250*2530 | 12062 |
WT-ME1875 | 1875/1500 | 1700/1360 | 310 | S16R-PTA | 16V | 65.4 | 24 | 1590 | Elec. | 5450*2250*2530 | 12340 |
WT-ME2050 | 2050/1640 | 1860/1488 | 418 | S16R-PTA2 | 16V | 65.4 | 24 | 1760 | Elec. | 5450*2250*2530 | 12475 |
WT-ME2200 | 2200/1760 | 2000/1600 | 432 | S16R-PTAA2 | 16V | 65.4 | 24 | 1895 | Elec. | 5780*2230*2550 | 13724 |
WT-ME2420 | 2420/1936 | 2200/1760 | 472.7 | S16R2-PTAW | 16V | 79.9 | 24 | 2167 | Elec. | 5990*2230*2550 | 14404 |
WT-ME2500 | 2500/2000 | 2270/1816 | 472.7 | S16R2-PTAW | 16V | 79.9 | 24 | 2167 | Elec. | 5990*2230*2550 | 14404 |
WT-ME MITSUBISHI SERIES SPECIFICATION 60HZ @ 1800RPM | |||||||||||
Genset Model | 60HZ PF=0.8 440/220V 3Phase 4Wire | Engine specification | Genset canopy data | Genset open data | |||||||
Standby Power | Prime Power | Cons 100%(L/H) | Engine Model | Cyl. | Gov. | Displacement(L) | Dimention(MM) | weight(KG) | Dimention(MM) | Weight(KG) | |
KVA/KW | KVA/KW | ||||||||||
WT-ME8 | 8.2/6.5 | 7.5/6 | 2.79 | L3E-W461DG | 3L | Elec | 0.952 | 1900*730*1130 | 625 | 1200*540*850 | 460 |
WT-ME13 | 12.5/10 | 11.5/9.2 | 4.27 | S3L2-W461DG | 3L | Elec | 1.318 | 1900*730*1130 | 625 | 1200*540*950 | 460 |
WT-ME26 | 26/21 | 23.5/19 | 9.06 | S4Q2-Y365DG | 4L | Elec | 2.505 | 1900*730*1130 | 700 | 1350*540*950 | 491 |
WT-ME35 | 35/28 | 32/26 | 11.42 | S4S-Y365DG | 4L | Elec | 3.331 | 2250*950*1280 | 835 | 1550*740*1250 | 693 |
WT-ME37 | 37/30 | 33.8/27 | 12.07 | S4S-Y365DG | 4L | Elec | 3.331 | 2250*950*1280 | 835 | 1550*740*1250 | 693 |
WT-ME44 | 44/35 | 40/32 | 14.92 | S4S-Y3DT65DG | 4L | Elec | 3.331 | 2250*950*1280 | 1090 | 1640*740*1250 | 890 |
WT-ME48 | 48/38 | 43.8/35 | 16.33 | S4S-Y3DT65DG | 4L | Elec | 3.331 | 2250*950*1280 | 1090 | 1640*740*1250 | 890 |
WT-ME330 | 330/264 | 300/240 | 93 | S6B-PTA2 | 6L | Elec | 12.88 | 4350*1500*2260 | 4020 | 3180*1350*1770 | 2858 |
WT-ME360 | 360/288 | 325/260 | 100.9 | S6B-PTA2 | 6L | Elec | 12.88 | 4350*1500*2260 | 4020 | 3180*1350*1770 | 2858 |
WT-ME395 | 395/316 | 360/288 | 106.9 | S6B3-PTA | 6L | Elec | 14.6 | 4350*1500*2260 | 4020 | 3180*1350*1770 | 3196 |
WT-ME440 | 440/352 | 400/320 | 118.8 | S6B3-PTA | 6L | Elec | 14.6 | 4350*1500*2260 | 4020 | 3180*1350*1770 | 3196 |
WT-ME500 | 500/400 | 450/360 | 137 | S6A3-PTA | 6L | Elec | 18.56 | 4650*1600*2260 | 5270 | 3530*1350*1850 | 3863 |
WT-ME525 | 525/420 | 475/380 | 144.6 | S6A3-PTA | 6L | Elec | 18.56 | 4650*1600*2260 | 5270 | 3530*1350*1850 | 3863 |
WT-ME535 | 535/428 | 488/390 | 148.6 | S6A3-PTA | 6L | Elec | 18.56 | 4650*1600*2260 | 5270 | 3530*1350*1850 | 3863 |
WT-ME600 | 600/480 | 550/440 | 168.5 | S6R-PTA | 6L | Elec | 24.51 | 4950*1800*2514 | 5630 | 3560*1410*1933 | 5210 |
WT-ME650 | 650/520 | 594/475 | 181.9 | S6R-PTA | 6L | Elec | 24.51 | 4950*1800*2514 | 5630 | 3560*1410*1933 | 5210 |
WT-ME710 | 710/568 | 645/516 | 197.7 | S6R-PTA | 6L | Elec | 24.51 | 4950*1800*2514 | 5630 | 3560*1410*1933 | 5210 |
WT-ME850 | 850/680 | 775/620 | 237.5 | S12A2-PTA | 12V | Elec | 33.93 | 20GP container | 12750 | 4050*1630*2080 | 6370 |
WT-ME880 | 880/704 | 800/640 | 245.1 | S12A2-PTA | 12V | Elec | 33.93 | 20GP container | 12750 | 4050*1630*2080 | 6370 |
WT-ME1170 | 1170/936 | 1063/850 | 313.4 | S12H-PTA | 12V | Elec | 37.11 | 20GP container | 12750 | 4330*1760*2380 | 8358 |
WT-ME1200 | 1200/960 | 1100/880 | 324.4 | S12H-PTA | 12V | Elec | 49.03 | 20GP container | 12750 | 4560*2250*2380 | 9435 |
WT-ME1320 | 1320/1056 | 1200/960 | 351.6 | S12R-PTA | 12V | Elec | 49.03 | 20GP container | 12750 | 4560*2250*2380 | 9435 |
WT-ME1415 | 1415/1132 | 1287/1030 | 377.1 | S12R-PTA | 12V | Elec | 49.03 | 20GP container | 12750 | 4560*2250*2380 | 9435 |
WT-ME1470 | 1470/1176 | 1338/1070 | 404.9 | S12R-PTA2 | 12V | Elec | 49.03 | 20GP container | 12750 | 4560*2250*2380 | 9548 |
WT-ME1600 | 1600/1280 | 1450/1160 | 438.8 | S12R-PTA2 | 12V | Elec | 49.03 | 20GP container | 12750 | 4560*2250*2380 | 9548 |
WT-ME1788 | 1788/1430 | 1625/1300 | 477 | S12R-PTAA2 | 12V | Elec | 49.03 | 20GP container | 12750 | 5030*2230*2550 | 10835 |
WT-ME1925 | 1925/1540 | 1750/1400 | 509.5 | S16R-PTA | 16V | Elec | 65.37 | 40HQ container | 20800 | 5450*2250*2530 | 12062 |
WT-ME2125 | 2125/1700 | 1925/1540 | 582.5 | S16R-PTA2 | 16V | Elec | 65.37 | 40HQ container | 20800 | 5450*2250*2530 | 12475 |
WT-ME2375 | 2375/1900 | 2150/1720 | 626 | S16R-PTAA2 | 16V | Elec | 65.37 | 40HQ container | 20800 | 5780*2230*2550 | 13724 |
A.STANDARD SUPPLY:1.Brand new CCEC/DCEC CUMMINS, MITSUBISHI, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG,water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatment
GENSET STANDARD SPECIFICATION | |||||||
Gensets model | Power output(KVA) | Power output (KW) | Mitsubishi Engine Model | Leroy somer Alternator | |||
PRP | ESP | PRP | ESP | ||||
WT-M1375 | 1250 | 1375 | 1000 | 1100 | S12R-PTA-C | LSA50.2M6 | |
(1) Available in the following voltages:220V-240V AND 380V-415V(440V)-50HZ | |||||||
(2) PRP:Prime Power-Continuous duty operation,under variable load 24/24-h-10% overload permissible 1 hour/12hours. | |||||||
(3) Rating Definitions (Operation at Altitude≤1000m, Ambient temperature≤40ºC)Continuous Power.These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercially purchased power.There is no limitation to the annual hours of operation and this model can supply 10% overload power for 1 hour in 12 hours. | |||||||
Engine & Alternator | |||||||
ENGINE–Industrial 4 stroke cooled diesel engine complete with air,fuel and oil filters,electric starting and charging equipment,engine protection against low water level. | |||||||
ALTERNATOR–Brushless,self exciting,self regulation,sreen protected,drip proof rated in accordance with IEC60034.Voltage regulation maintainted within ±0.5% from no load to full load.between 0.8 lagging and unity.All standard voltages available. | |||||||
COOLING–Radiator and colling fan complete with protection guards,designed to cool engine at specified output in air temperatures upto 45ºC,radiators suitable for higher temperatures are available.Low water level protection fitted as standard. | |||||||
ELECTRICAL SYSTEM–24V upto.Axial type starter motor,battery charging alternator,high capacity lead acid battery,and battery tray mounted on the generator base frame,and heavy duty interconnecting cable with terminations. | |||||||
EXHAUST SYSTEM--Heavy duty industrial exhauset silencer with flexible piping. | |||||||
Technical Data Sheet | |||||||
Generating sets model: | |||||||
400V,50Hz,1500 rpm | Genset Option Features | ||||||
Engine Model: | MitsubishiS12R-PTA-C | ΔLow fuel level alarm shutdown | |||||
Type | 12 V cylinder,4 cycle diesel | ΔAutomatic Fuel Filling System | |||||
Aspiration | Turbocharged inter-cooled | ΔEngine oil feeding and drain pump | |||||
Bore/Stroke mm | 170X180 | ΔAuto Transfter Switch( ATS) | |||||
Compress the ratio | 14.0 : 1 | ΔParallel control panels | |||||
Cooling system | Water-cooled | ΔCircuit Breaker MCCB & ACB | |||||
100% Load Fuel Consumption g/kwh | 197 | ΔRemote Control Panel | |||||
Engine Speed/Frequency RPM/Hz | 1500/50HZ | Δweatherproof/soundproof Canopy | |||||
Rated Output kw/bHP | 1080/1448 | ΔTrailer type Gensets | |||||
Exhaust air flow (m3/min) | 89 | QUALITY STANDARDS | |||||
Coolant Capacity L | 125 | ISO9001:2000,ISO14000,ISO3046 | |||||
Starting System | Electric 24 volt DC | ISO8528 BS4999 | |||||
Displacement L | 49.03 | BS5514,AS1359,ICE34 | |||||
Lubricant system Capacity L | 180 | CE Compliance | |||||
Battery Volatge / Capacity | 24VDC | Gensets Dimensions & Weight | |||||
Governing Type | Electrical (GAC governor) | Open type:L*W*H,mm | |||||
Exhaust Gas TemperatureºC | 98 | 5382×2486×2931 | |||||
Exhaust Gas flow m3/min | 235 | Silent type:L*W*H,mm | |||||
Noise level dBA@7m | ≤85dBA(silent type) | 40GP container | |||||
Alternator Technical data | |||||||
Leroy somer | |||||||
ΔBruxhless,self exciting | Exciter | Brushless | |||||
Δclass "H" insulation | Cooling Fan | Cast alloy aluminum | |||||
ΔStandard degree of protection is IP23 | Bearing | Single,double shielded | |||||
Δself regulating | Windings | 100% copper | |||||
ΔWith fan cooling | Connection Type | Reconnectable | |||||
ΔResist Humid grease | Insulation Type | Class H | |||||
ΔAC excitation,roating rectification tube | Pitch | 2/3 | |||||
ΔStator grease insulation covered | Amortisseur Winding | Full | |||||
ΔRotator and exciation high polymer,Resist the corruption of oil and acid | Voltage Regulator | AVR R250 | |||||
Voltage Regulator NL-FL | ±0.5% | ||||||
ΔRotator ballance is in accordance with BS5625 standard 12.5 | Underspeed Protection | Standard | |||||
Overexcitation Protection | IP23 | ||||||
ΔHigh-quality lubrication sealed long-time bearing | TIF (1960 Weightings) | <50 | |||||
ΔRotator sillicon steel close tight | Exciation System | AREP | |||||
Control Panel – DEEPSEA7320 | |||||||
The base mounted control panel in a vibration isolated sheet steel enclosure.The control panel is equipped as follows: | |||||||
a)Instruments:Analogue Volmeter,Hours Run Meter.Water pressure Meter. | |||||||
b) Controls:Emergency Stop Pushbutton,Volmeter Phase Selector Switch. | |||||||
c) Control module:Standard collocation is DSE7320 Auto start . |
