Cummins Diesel Power Generator Set Dg Genset 500kVA 575kVA 625kVA 650kVA 750kVA

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1000 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:
Available

| Customized Request


Product Detail

Product Tags

Basic Info.

Model NO.
WT-C688
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V, 380/220V, 440/220V, 415/240V, 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17:1
Alternator
Brushless, Self Exciting, 100% Copper
Voltage Regulator
AVR, Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
2900x980x1550MM
Trademark
WINTPOWER
Origin
China
HS Code
85021310
Production Capacity
8000

Product Description

Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7

WT-C CUMMINS SERIES SPECIFICATION 50HZ @1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine Model cyl displacement Battery Vol. Max power Gov. Open Type Dimension
Standby Power Prime Power Cons 100%(L/H)
KVA/KW KVA/KW L V KW L×W×H(MM) Weight KG
WT-C30 30/24 25/20 6.7 4B3.9G2 4L 3.9 24 27 Elec. 1725*950*1500 830
WT-C44 44/35 40/32 9.3 4BT3.9G2 4L 3.9 24 40 Elec. 1870*950*1500 950
WT-C55 55/44 50/40 12.9 4BTA3.9-G2(QC50/60E) 4L 3.9 24 55 Elec. 1870*950*1500 950
WT-C70 70/56 63/50 12.9 4BTA3.9-G2(QC58/67E) 4L 3.9 24 55 Elec. 1870*950*1500 990
WT-C88 88/70 70/64 17.6 4BTA3.9-G11 4L 3.9 24 80 Elec. 1870*950*1500 990
WT-C100 100/80 90/72 22.3 6BT5.9G2 6L 5.9 24 92 Elec. 2220*950*1530 1200
WT-C110 110/88 100/80 22.3 6BT5.9G2 6L 5.9 24 92 Elec. 2250*950*1530 1200
WT-C125 125/100 113/90 27 6BTA5.9G2 6L 5.9 24 116 Elec. 2400*950*1530 1200
WT-C138 138/110 125/100 30 6BTAA5.9G2 6L 5.9 24 130 Elec. 2400*950*1530 1240
WT-C150 150/120 135/110 30 6BTAA5.9G2 6L 5.9 24 130 Elec. 2400*950*1530 1360
WT-C165 165/132 150/120 34 6BTAA5.9-G12 6L 5.9 24 155 Elec. 2400*950*1530 1360
WT-C175 175/140 158/128 42 6CTA8.3G2 6L 8.3 24 180 Elec. 2420*950*1690 1690
WT-C206 206/165 185/150 42 6CTA8.3G2 6L 8.3 24 180 Elec. 2420*950*1690 1690
WT-C220 220/176 200/160 45 6CTAA8.3G2 6L 8.3 24 203 Elec. 2540*950*1750 1810
WT-C250 250/200 230/184 53 6LTAA8.9-G2 6L 8.9 24 240 Elec. 2580*1020*1670 2030
WT-C275 275/220 250/200 53 6LTAA8.9G3 6L 8.9 24 240 Elec. 2580*1020*1670 2030
WT-C413 413/330 375/300 76.5 6ZTAA13-G3 6L 13 24 380 Elec. 3110*1360*1920 3000
WT-C440 440/352 400/320 89.1 6ZTAA13-G2 6L 13 24 415 Elec. 3110*1360*1920 3000
WT-C480 480/384 438/350 89.1 6ZTAA13-G2 6L 13 24 415 Elec. 3110*1360*1920 3000
WT-C500 500/400 450/360 91.4 6ZTAA13-G4 6L 13 24 415 Elec. 3110*1360*1920 3000
WT-C500 500/400 450/360 88.8 QSZ13G2 6L 13 24 400 ECM 3100*1450*1950 3120
WT-C530 530/424 500/400 101 QSZ13G3 6L 13 24 450 ECM 3100*1450*2050 3150
WT-C275 275/220 250/200 55 MTA11G2A 6L 10.8 24 257 Elec. 2900*1200*1690 3100
WT-C275 275/220 250/200 53 NT855GA 6L 14 24 254 Elec. 2950*1200*1740 3007
WT-C313 313/250 275/220 61 NTA855G1A 6L 14 24 291 Elec. 3050*1200*1740 3260
WT-C350 350/280 313/250 63 MTAA11-G3 6L 10.8 24 310 Elec. 3050*1200*1690 3350
WT-C350 350/280 313/250 68 NTA855G1B 6L 14 24 321 Elec. 3050*1200*1740 3340
WT-C355 355/284 325/260 69 QSM11-G2 6L 10.8 24 321 Elec. 3050*1200*1690 3350
WT-C388 388/310 350/280 72 NTA855G2A 6L 14 24 343 Elec. 3050*1200*1740 3355
WT-C388 388/310 350/280 75 NTA855G4 6L 14 24 351 Elec. 3050*1200*1740 3355
WT-C413 413/330 375/300 86 NTAA855G7 6L 14 24 377 Elec. 3250*1230*1800 3485
WT-C440 440/352 400/320 89 NTAA855G7A 6L 14 24 406 Elec. 3250*1230*1800 3485
WT-C500 500/400 450/360 97 WTA19G3 6L 18.9 24 448 Elec. 3380*1390*2050 4166
WT-C550 550/440 500/400 107 KTAG3A 6L 19 24 504 Elec. 3380*1390*2050 4166
WT-C550 550/440 500/400 107 KTA19G4 6L 18.9 24 504 Elec. 3380*1390*2050 4166
WT-C575 575/460 525/420 113 KTAA19G5 6L 18.9 24 555 Elec. 3670*1680*2190 4650
WT-C625 625/500 575/460 118.5 KTAA19G6 6L 18.9 24 570 Elec. 3670*1680*2190 4658
WT-C650 650/520 600/480 139 KTA19G8 6L 18.9 24 575 Elec. 3380*1390*2050 5365
WT-C688 688/550 625/500 127.8 KTAA19G6A 6L 18.9 24 610 Elec. 3720*1680*2190 4813
WT-C750 750/600 688/550 127.8 KTAA19G7 6L 18.9 24 610 Elec. 3720*1680*2190 4813
WT-C713 713/570 650/520 143 QSK19G3 6L 19 24 634 Elec. 3620*1720*2320 4909
WT-C800 800/640 725/580 157 KT38-GA 12V 37.8 24 711 Elec. 4410*1720*2170 7190
WT-C825 825/660 750/600 167 KTA38G2 12V 37.8 24 731 Elec. 4410*1720*2170 7190
WT-C880 880/704 800/640 170 KTA38G2B 12V 38 24 790 Elec. 4410*1720*2170 7199
WT-C1000 1000/800 900/720 191 KTA38G2A 12V 37.8 24 895 Elec. 4410*1720*2170 7359
WT-C1100 1100/880 1000/800 209 KTA38G5 12V 37.8 24 970 Elec. 4300*2080*2190 7777
WT-C1250 1250/1000 1135/908 251 KTA38G9 12V 38 24 1090 Elec. 4400*2080*2190 8156
WT-C1375 1375/1100 1250/1000 254 KTA50G3 16V 50.3 24 1227 Elec. 5000*2080*2290 9281
WT-C1375 1375/1100 1250/1000 274 QSK38G5 12V 37.7 24 1224 Elec. 4650*2160*2440 8547
WT-C1500 1500/1200 1375/1100 289 KTA50G8 16V 50.3 24 1429 Elec. 4960*2200*2620 10371
WT-C1650 1650/1320 1500/1200 289 KTA50GS8 16V 50.3 24 1429 Elec. 5170*2120*2360 10762
WT-C CUMMINS SERIES SPECIFICATION 60HZ @1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine specification Genset canopy data Genset open data
Standby Power Prime Power Cons 100%(L/H) Engine Model Cyl. Gov. Displacement(L) Dimention(MM) weight(KG) Dimention(MM) Weight(KG)
KVA/KW KVA/KW
WT-C35 35/28 31/25 8.6 4B3.9G2 4L Elec. 3.9 2450*1080*1865 1350 1725*950*1500 830
WT-C55 55/44 50/40 10.7 4BT3.9G2 4L Elec. 3.9 2450*1080*1865 1350 1725*950*1500 830
WT-C75 75/60 68/54 15.9 4BTA3.9G2 4L Elec. 3.9 2670*1080*1865 1460 1870*950*1500 950
WT-C93 93/74 85/68 20.1 4BTA3.9-G11 4L Elec. 3.9 2670*1080*1865 1460 1870*950*1500 950
WT-C125 125/100 110/68 28.5 6BT5.9G2 6L Elec. 5.9 2900*1080*2000 1780 2220*950*1530 1200
WT-C138 138/110 125/100 27 6BTA5.9G2 6L Elec. 5.9 3200*1080*2000 1780 2400*950*1530 1200
WT-C165 165/132 150/120 30 6BTAA5.9G2 6L Elec. 5.9 3200*1080*2000 1780 2400*950*1530 1240
WT-C175 175/148 160/128 38 6BTAA5.9G12 6L Elec. 5.9 3200*1080*2000 1780 2400*950*1530 1240
WT-C185 185/186 168/135 44 6CTA8.3G2 6L Elec. 8.3 3500*1080*2120 2150 2420*950*1690 1690
WT-C200 200/160 180/144 44 6CTA8.3G2 6L Elec. 8.3 3500*1080*2120 2150 2420*950*1690 1690
WT-C220 220/176 200/160 44 6CTA8.3G2 6L Elec. 8.3 3500*1080*2120 2150 2420*950*1690 1690
WT-C250 250/200 225/180 49 6CTAA8.3G2 6L Elec. 8.3 3500*1080*2120 2520 2540*950*1750 1810
WT-C275 275/220 250/200 53 6LTAA8.9G2 6L Elec. 8.3 3700*1090*2080 2980 2580*1020*1670 2030
WT-C413 413/330 375/300 81 6ZTAA13-G3 6L Elec. 13 4350*1400*2260 4020 3050*1200*1740 3260
WT-C440 440/352 400/320 96 6ZTAA13-G2 6L Elec. 13 4350*1400*2260 4020 3050*1200*1740 3260
WT-C480 480/384 438/350 96 6ZTAA13-G2 6L Elec. 13 4350*1400*2260 4020 3050*1200*1740 3260
WT-C500 500/400 450/360 91 6ZTAA13-G4 6L Elec. 13 4350*1400*2260 4020 3050*1200*1740 3260
WT-C500 500/400 450/360 89 QSZ13-G2 6L ECM 13 4350*1400*2260 4020 3050*1200*1740 3260
WT-C530 530/424 500/400 104.1 QSZ13-G3 6L ECM 13 4350*1400*2260 4020 3050*1200*1740 3260
WT-C330 330/264 300/240 73.4 NTA855G1 6L Elec. 14 4350*1400*2260 4020 3050*1200*1740 3260
WT-C344 344/275 313/250 76.5 NTA855-G1 6L Elec. 14 4350*1400*2260 4020 3050*1200*1740 3340
WT-C388 388/310 350/280 80.5 NTA855G1B 6L Elec. 14 4350*1400*2260 4020 3050*1200*1740 3260
WT-C440 440/352 400/320 87 NTA855G4 6L Elec. 14 4350*1400*2260 4020 3050*1200*1740 3340
WT-C500 500/400 450/360 98 KTA19G2 6L Elec. 18.9 4650*1600*2260 5270 3380*1390*2050 4166
WT-C550 550/440 500/400 111 KTA19G3 6L Elec. 18.9 4650*1600*2260 5270 3380*1390*2050 4166
WT-C625 625/500 563/450 120 KTA19G3A 6L Elec. 18.9 4650*1600*2260 5270 3380*1390*2050 4166
WT-C625 625/500 563/450 120 KTA19G4 6L Elec. 18.9 4650*1600*2260 5270 3380*1390*2050 4166
WT-C688 688/550 625/500 134 KTAA19G5 6L Elec. 18.9 4950*2000*2514 5930 3670*1680*2190 4650
WT-C700 700/560 638/510 140 QSKTAA19G4 6L ECM 18.9 4950*2000*2514 5930 3720*1680*2190 4813
WT-C750 750/600 688/550 140 KTAA19G6A 6L Elec. 18.9 4950*2000*2514 5930 3720*1680*2190 4813
WT-C750 750/600 688/550 151 QSKTAA19G5 6L ECM 18.9 4950*2000*2514 5930 3720*1680*2190 4813
WT-C825 825/660 750/600 140 KTAA19G7 6L Elec. 18.9 4950*2000*2514 5930 3720*1680*2190 4813
WT-C850 850/680 775/620 154 KT38G 12V Elec. 37.8 20GP container 10250 4410*1720*2170 7190
WT-C1000 1000/800 925/740 204 KTA38G2 12V Elec. 37.8 20GP container 10250 4410*1720*2170 7190
WT-C1100 1100/880 1000/800 225 KTA38G2A 12V Elec. 37.8 20GP container 10250 4410*1720*2170 7190
WT-C1250 1250/1000 1125/900 245 KTA38G4 12V Elec. 37.8 20GP container 12160 4300*2080*2190 7777
WT-C1320 1320/1056 1200/960 274 QSK38-G5 12V ECM 37.7 20GP container 20800 5000*2080*2290 9281
WT-C1375 1375/1100 1250/1000 274 KTA38-G9 12V Elec. 37.8 20GP container 20800 5000*2080*2290 9281
WT-C1450 1450/1160 1200/960 274 QSK38-G5 12V ECM 37.7 40HQ container 20800 4650*2160*2440 8547
WT-C1575 1575/1260 1432/1145 282 KTA50G3 16V Elec. 50.3 40HQ container 21400 4960*2200*2620 10371
WT-C1650 1650/1320 1500/1200 330 KTA50G9 16V Elec. 50.3 40HQ container 21400 5300*2150*2550 10762
WT-C1720 1720/1376 1563/1250 330 KTA50G9 16V Elec. 50.3 40HQ container 21400 5300*2150*2550 10762
WT-C1875 1875/1500 1687/1350 330 KTA50G9 16V Elec. 50.3 40HQ container 21400 5300*2150*2550 10762

A.STANDARD SUPPLY:1.Brand newCCEC/DCEC, MITSUBISHI, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG, water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3phase brushless alternator with 100% copper, IP23 and Hinsulation class.3.Standard50ºCradiator with safety guard, engine driven fan mounted on skid4.DEEPSEA, COMAP, SMARTGENcontroller brand with Auto/Manual start and AMF function5.DELIXI, CHINT or ABB branded MCCB circuit breaker mounted.6.Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7.Complete set mounted on abased frame with anti-vibration mountings.8.Industrial 9dB muffler exhaust system with blexible connects and bellows.9.Based frame with fuel, oil and coolant drain cocks for easy maintenance.10.12/24V DC electric start system with free maintaining battery &floating battery charger.11.Standard with built-in fuel tank for 8hours running. Canopy noise levels @7 meters with 70 dB12.Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY:1.Weatherproof canopy /Soundproof canopy /Trailer-mounted2.Engine /Alternator Pre-heaters3.Auto load sharing &synchronizing panel4.Build-in ATS (Auto start &stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factoryinspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%Δ Wintpower Silent type Diesel Generator, advantages as follows:1. Integrated interface with humanized and practicably design2. Super silent material and treatment reach 70dBA@1M full load3. Steel material thickness 2MM to 4MM, cut and fold by CNC4. New safe door handle, updated lock, bottom forklift and top lift5. Aviation outtake connector ad operation LED light6. Free maintenance battery with floating charger8. 8-24 hours base fuel tank with electrical fuel indicator9. Powder coating canopies after chemistry treatment

STANDARD SPECIFICATION
50HZ, 1500RPM,3-PHASE, 400/230V
Gensets model Power output(KVA) Power output (KW) Cummins Engine Model Leroy Somer Alternator
PRP ESP PRP ESP
WT-C688 630 688 500 550 KTAA19G6A TAL-A47-E
Note:
(1) Available in the following voltages:220V-2770V AND 380V-480V(440V)
(2) PRP:Prime Power-Continuous duty operation,under variable load 24/24-h-10% overload permissible 1 hour/12hours.
(3) Rating Definitions (Operation at Altitude≤1000m, Ambient temperature≤40ºC)Continuous Power.These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercially purchased power.
Engine & Alternator
ENGINE–Industrial 4 stroke cooled diesel engine complete with air,fuel and oil filters,electric starting and charging equipment,engine protection against low water level.
ALTERNATOR–Brushless,self exciting,self regulation,sreen protected,drip proof rated in accordance with IEC60034.Voltage regulation maintainted within ±0.5% from no load to full load.between 0.8 lagging and unity.All standard voltages available.
COOLING–Radiator and colling fan complete with protection guards,designed to cool engine at specified output in air temperatures upto 45ºC,radiators suitable for higher temperatures are available.Low water level protection fitted as standard.
ELECTRICAL SYSTEM–24V upto.Axial type starter motor,battery charging alternator,high capacity lead acid battery,and battery tray mounted on the generator base frame,and heavy duty interconnecting cable with terminations.
EXHAUST SYSTEM--Heavy duty industrial exhauset silencer with flexible piping.
Technical Data Sheet
Generating sets model:
400/230V,50Hz,1500 rpm Genset Option Features
Engine Model: Cummins KTAA19G6A ΔLow fuel level alarm shutdown
Type 6 cylinder,4 cycle diesel ΔAutomatic Fuel Filling System
Aspiration Turbocharged ΔEngine oil feeding and drain pump
Bore/Stroke mm 159X159 ΔAuto Transfter Switch( ATS)
Compress the ratio 13.0:1 ΔParallel control panels
Cooling system Water-cooled ΔCircuit Breaker MCCB & ACB
100% Load Fuel Consumption L/H 168 ΔRemote Control Panel
Engine Speed/Frequency RPM/Hz 1500/50HZ Δweatherproof/soundproof Canopy
Rated Output kw/Bhp 610/818 ΔTrailer type Gensets
Exhaust air flow (m3/min) 588 QUALITY STANDARDS
Coolant Capacity L 91 ISO9001:2020,ISO14001,ISO3046
Starting System Electric 24 volt DC ISO8528 BS4999
Displacement L 18.9 BS5514,AS1359,ICE34
Lubricant system Capacity L 50 CE Compliance
Battery Volatge / Capacity 24VDC Gensets Dimensions & Weight
Governing Type Electrical (GAC governor) Open type:L*W*H,mm
Exhaust Gas TemperatureºC 490 3280×1305×1950
Exhaust Gas flow m3/min 119.5 Enclosure type:L*W*H,mm
Noise level dBA@1m ≤80dBA(canopy type) 5200×1800×2200
Alternator Technical data
Leroy Somer TAL-A47-E
Δ Bruxhless,self exciting Exciter Brushless
Δ Class “H” insulation Cooling Fan Cast alloy aluminum
Δ Standard degree of protection is IP23 Bearing Single,double shielded
Δ Self regulating Windings 100% copper
Δ With fan cooling Connection Type Reconnectable
Δ Resist Humid grease Insulation Type Class H
Δ AC excitation,roating rectification tube Pitch 2/3
Δ Stator grease insulation covered Amortisseur Winding Full
Δ Rotator and exciation high polymer,Resist the corruption of oil and acid Voltage Regulator R250
Voltage Regulator NL-FL ±0.5%
Δ Rotator ballance is in accordance with BS5625 standard 12.5 Underspeed Protection Standard
Overexcitation Protection IP23
Δ High-quality lubrication sealed long-time bearing TIF (1960 Weightings) <50
Δ Rotator sillicon steel close tight Exciation System AREP
Control Panel – DEEPSEA6120
The base mounted control panel in a vibration isolated sheet steel enclosure.The control panel is equipped as follows:
a) Instruments:Analogue Volmeter,Hours Run Meter.Water pressure Meter.
b) Controls:Emergency Stop Pushbutton,Volmeter Phase Selector Switch.
c) Control module:Standard collocation is DSE6120 Auto start .

Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7Cummins Diesel Power Generator Set Dg Genset 500kVA Kta19g3a Kta19g4 575kVA 625kVA Ktaa19g5 Ktaa19g6 650kVA Kta19g8 Ktaa19g6a 750kVA Ktaa19g7ΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWERService SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using forWINTPOWERProducts Serving the customers,WINTPOWERgains trust .Work together with Customers During the service period,WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator,WINTPOWERhelp customeruntilthey know how to useΔWINTPOWERService PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.

  • Previous:
  • Next:
    • Write your message here and send it to us

    Products categories

    Hit enter to search or ESC to close
