Cummins CCEC NTA855 SERIES MAINTENACE SPARE PARTS | ||||||
Item | Part Name | QTY | Part Number | Maintenance Peried | ||
1 | CARTRIDGE, LUB | 12 | LF670 | 250hrs | 500hrs | 2250hrs, 3600hrs |
2 | ELEMENT,LUBOIL FILTER | 12 | LF777 | |||
3 | FILTER,FUEL | 24 | FS1212 | |||
4 | water filter /CORROSION RESISTOR | 3 | WF2075 | |||
5 | CLEANER,AIR | 3 | AF928M | |||
6 | BELT,V | 2 | 178708 | |||
7 | BELT,V RIBBED | 1 | 217638 | |||
8 | BELT,V | 2 | 3040303 | |||
9 | TURBOCHARGER ,KIT | 1 | 381523 | |||
10 | BEARING,THRUST | 2 | 3067568 | |||
11 | BEARING,CONNECTING | 1 | 214950 | |||
12 | SET,MAIN BEARING | 1 | 3802160 | |||
13 | VALVE,EXHAUST | 12 | 135957 | |||
14 | VALVE,INTAKE | 12 | 145701 | |||
15 | COLLET,VALVE | 24 | 127554 | |||
16 | CUIDE,VALVE SPRING | 12 | 170296 | |||
17 | GUIDE,VALVE SRRING | 12 | 3042745 | |||
18 | INSERT,VALVE EXHAUST | 24 | 200354 | |||
19 | INSERT,INTAKE VALVE | 24 | 3017759 | |||
20 | GUIDE,VALVE STEM | 24 | 3006456 | |||
21 | VALVE,SPRING | 24 | 211999 | |||
22 | STEEVE,INJECTOR | 6 | 3011934 | |||
23 | INJECTOR | 6 | 3054228 | |||
24 | NOZZLE,PISTION COOLING | 6 | 3013591 | |||
25 | THERMOSTAT | 1 | 3076489 | |||
26 | SET,UPPER ENGINE GSK | 1 | 3801330 | |||
27 | SET,LOWER ENGINE GSK | 1 | 3801648 | |||
28 | OIL PRESSURE sensor | 1 | 3015237 | |||
29 | water temp sensor | 2 | 3015238 | |||
30 | speed sensor | 1 | 3034571 | |||
31 | BUSHING | 6 | 387420 | |||
32 | BUSHING | 12 | 132770 | |||
33 | OIL PUMP | 1 | 3042378 | |||
34 | MOTOR,STARING | 1 | 3021036 | |||
35 | ALTERNATOR | 1 | 4060811 | |||
36 | WATER,PUMP | 1 | 3051384 | |||
37 | PISTON,ENGINE | 6 | 3017348 | |||
38 | PIN,PISTON | 6 | 191970 | |||
39 | PISTON,ENGINE | 6 | 3801506 | |||
40 | RING,REATING | 12 | 175755 | |||
41 | LINER,CYLINDER | 6 | 3055099 | |||
42 | SEAL,DREVICE | 6 | 215090 | |||
43 | SEAL,O RING | 12 | 3032874 | |||
44 | CYLINDER,GASKET | 3 | 3047402 | |||
45 | BHAFT ACCESORY DRIVE | 1 | 3000171 | |||
46 | SHAFT,ROCKER LEVER | 6 | 3038904 | |||
47 | CAMSHAFT | 1 | 3025518 | |||
48 | BELT TENSIONER | 1 | 3529035 | |||
49 | NT855 Fuel Pump | 1 | 4951459 | |||
Item | Part Name | Part Specification | Model | Brand | ||
1 | Cummins starting motor | 12V/24V | 232C-1115030 | Cummins engine starer | ||
2 | Charging alternator | 4060811 24V | 3021036 | Cummins alternator |
ΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally, we can delivery in 5-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
