Mitsubishi S6b3 Engine Part F3015-04522 F3015-03222 F3153-07500

Mitsubishi S6b3 Engine Part F3015-04522 F3015-03222 F3153-07500

Quick Details:

Conditions
of Use:
Car Type, Trailer Type, Marine, Land Use
Usage: Emergency Crew, Standby Unit, Common Units
Output Type: AC Three Phase
Cooling
Method:
Water Cooling
Installation
Method:
Fixed
Generator
Type:
Diesel Generator
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-MP07500
Engine Speed
1500rpm/1800rpm
Frequency
50Hz/60Hz
Aspiration Engine Typ
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17.0:1
Delivery
by Shipping or by Airway
Part Type
Brand New
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Packing with Carton
Specification
600x250x500MM
Trademark
MITSUBISHI
Origin
Japan
HS Code
850300
Production Capacity
8000

Product Description

Mitsubishi S6b3 Engine Part 36204-16500 34A07-04400 36207-01500 34A45-00300 Me055030 34A45-12600 F3015-04522 F3015-03222 F3153-07500

MHI S6B3 ENGINE OVERHAULING KIT Mitsubishi engine maintenance part list
1 34A94-60050 GASKET KI O/H 1 1 1
2 34A07-42100 CYL. LINER 6 3 18
3 32517-13100 PIN, PISTON 6 2 12
4 36204-30100 VALVE, INLET 12 1 12
5 36204-41101 VALVE, EXHAUST 12 2 24
6 34A07-26200 SEAL, OIL 1 3 3
7 34A07-16300 SEAL, OIL 1 2 2
8 F3202-05500 RING SNAP 12 3 36
9 34A17-00400 PISTON, D135 6 3 18
10 34A17-01010 RING SET, PISTON 6 5 30
11 34A19-24100 BEARING 12 5 60
12 34A09-30010 METAL, MAIN SET 7 1 7
13 32509-38100 BEARING, THRUST 4 4 16
14 34A01-30401 SEAT, VALVE 12 4 48
15 36201-20601 SEAT, FINISH EX 12 4 48
16 36219-01600 BUSHING, CON-ROD 6 5 30
17 47220-38802 ELEMENT ASSY 1 5 5
18 34A01-02200 GASKET, CYL. HEAD S6B/S6B3 6 6 36
19 36204-16500 MHI-PACKING, ROCKER COVER 6 6 36
20 34A07-04400 O-RING, LINER WT 6 6 36
21 36207-01500 PACKING, LINER S6B/S6B3 12 10 120
22 34A45-00300 SHAFT, WATER PUMP S6B3/SEP425/475 1 2 2
23 ME055030 IMPELLER, WATER PUMP 1 1 1
24 34A45-12600 SEAL UNIT 1 2 2
25 f3015-04522 SEAL, OIL 1 5 5
26 f3015-03222 SEAL, OIL 1 3 3
27 F3153-07500 O-RING 1 1 1

Mitsubishi S6b3 Engine Part 36204-16500 34A07-04400 36207-01500 34A45-00300 Me055030 34A45-12600 F3015-04522 F3015-03222 F3153-07500Mitsubishi S6b3 Engine Part 36204-16500 34A07-04400 36207-01500 34A45-00300 Me055030 34A45-12600 F3015-04522 F3015-03222 F3153-07500Mitsubishi S6b3 Engine Part 36204-16500 34A07-04400 36207-01500 34A45-00300 Me055030 34A45-12600 F3015-04522 F3015-03222 F3153-07500Mitsubishi S6b3 Engine Part 36204-16500 34A07-04400 36207-01500 34A45-00300 Me055030 34A45-12600 F3015-04522 F3015-03222 F3153-07500Mitsubishi S6b3 Engine Part 36204-16500 34A07-04400 36207-01500 34A45-00300 Me055030 34A45-12600 F3015-04522 F3015-03222 F3153-07500ΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
