Perkins 2806c-E18tag3 Engine Part Krp3016 CH11684 CH11494 CH11021

Perkins 2806c-E18tag3 Engine Part Krp3016 CH11684 CH11494 CH11021

Quick Details:

Conditions
of Use:
Car Type, Trailer Type, Marine, Land Use
Usage: Emergency Crew, Standby Unit, Common Units
Output Type: AC Three Phase
Cooling
Method:
Water Cooling
Installation
Method:
Fixed
Generator
Type:
Diesel Generator
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-P10716
Engine Speed
1500rpm/1800rpm
Frequency
50Hz/60Hz
Aspiration Engine Typ
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17.0:1
Delivery
by Shipping or by Airway
Part Type
Brand New
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Packing with Carton
Specification
300x180x100MM
Trademark
Perkins
Origin
UK
HS Code
850300
Production Capacity
8000

Product Description

Perkins 2806c-E18tag3 Engine Part Krp3016 CH11684 CH11494 CH11021 CH11022 CH10724CH10019CH10731CH10732CH11487CH11489CH10715CH10716

EngineModel 2806C-E18TAG3 SERIES
A.Main warranty parts
Spare Parts Name P/N (part number) QTY Unit Price(USD)
AIR FILTER SEV551F/4 1 $420
OIL FILTER CH10929 1 $71
FUEL FILTER CH10930 1 $65
FUEL FILTER CH10931 1 $78
KIT,SERVICE KRP1568 1 $193
GASKET ROCKER COVER CH11353 1 $105
THERMOSTAT KRP1645 1 $432
FAN BELT CH11186 1 $180
ALT BELT CH11037 1 $22
B.Main warranty parts
Spare Parts Name P/N (part number) QTY Unit Price(USD)
REAR OIL SEAL CH11379 1 $211
FRONT OIL SEAL CH11304 1 $195
KIT,TOP OHAUL KRP1656 1 $1,482
KIT,BTM OHAUL KRP1657 1 $2,455
MAIN BEARING KRP3122 1 $1,000
BIG END BEARING KRP3016 1 $783
CONROD BOLT CH11684 24 $96
CONROD PIN CH11494 12 $18
VALVE INLET CH11021 12 $78
VALVE EXHAUST CH11022 12 $74
VALVE GUIDE CH10724 24 $34
COTTER CH10019 48 $7
INSERT INLET CH10731 12 $93
INSERT EXHAUST CH10732 12 $87
VALVE SPRING(INNER) CH11487 24 $8
VALVE SPRING(OUTER) CH11489 24 $4
VALVE SPRING SEAT(UPPE) CH10715 24 $30
VALVE SPRING SEAT(LOW) CH10716 24 $7
VALVE BRIDGE ASSY CH10680 12
KIT, PISTON KRP3014 6
KIT, PISTON KRP3026 6 $1,080
KIT, PISTON RING KRP3015 6 $531
KIT, PISTON RING KRP3021 6 $261
LINER CH12742 6 $557
LINER BAND CH10673 6 $12
LINER SEAL CH11654 6 $19
Spare Parts Name P/N (part number) QTY Unit Price(USD)
LINER SEAL CH11656 6 $25
LINER SEAL CH11655 6 $50
THRUST WASHER KRP3206 1 $225
JET CH11510 6 $366
INJECTOR CH11659 6 $1,931
INJECTOR SLEEVE CH11311 6 $74
INJECTOR SEAL KRP1643 6 $24
ROCKER SHAFT CH12695 3 $822
ROCKER ARM ASSY CH11165 12 $322
ROCKER ARM ASSY CH12698 6 $863
TURBOCHARGER ASSY CH11607 1 $3,263
TURBOCHARGER ASSY CH11608 1 $3,263
WATER PUMP ASSY. KRP1715 1 $4,338
LIFT PUMP KRP1679 1 $582
OIL COOLER ASSY CH11631 1 $8,239
CORE CH11116 1 $767
ALTERNATOR CH11087 1 $1,203
STARTER MOTOR CH11441 1 $2,242
WATER LEVEL SWITCH CV25001 1 $206
OIL PUMP CH10860 1 $2,299
ELECTRINIC CONTROL UN CH12800R 1 $8,023
OIL RESSURE SWITCH KRP1559 1 $257
OIL RESSURE GAUDE KRP1560 1 $332
TEMPERATURE SWITCH KRP1557 1 $156
SPEED SENSOR KRP1561 1 $515
OIL RESSURE SWITCH CV18339/2 1 $186
OIL RESSURE GAUDE 350-040-009 1
TEMPERATURE SWITCH CV18338/5 1 $114
TEMPERATURE GAUDE 310-040-006 1
KIT,CONROD CH11507 6 $1,713

Perkins 2806c-E18tag3 Engine Part Krp3016 CH11684 CH11494 CH11021 CH11022 CH10724CH10019CH10731CH10732CH11487CH11489CH10715CH10716Perkins 2806c-E18tag3 Engine Part Krp3016 CH11684 CH11494 CH11021 CH11022 CH10724CH10019CH10731CH10732CH11487CH11489CH10715CH10716Perkins 2806c-E18tag3 Engine Part Krp3016 CH11684 CH11494 CH11021 CH11022 CH10724CH10019CH10731CH10732CH11487CH11489CH10715CH10716Perkins 2806c-E18tag3 Engine Part Krp3016 CH11684 CH11494 CH11021 CH11022 CH10724CH10019CH10731CH10732CH11487CH11489CH10715CH10716Perkins 2806c-E18tag3 Engine Part Krp3016 CH11684 CH11494 CH11021 CH11022 CH10724CH10019CH10731CH10732CH11487CH11489CH10715CH10716ΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
