EngineModel | 4012-46TWG2A SERIES(DGKM6005) | |||
A.Main warranty parts | ||||
Spare Parts Name | P/N (part number) | QTY | Unit Price(USD) | |
AIR FILTER | SEV551H/4 | 2 | $677 | |
OIL FILTER | SE111B | 6 | $27 | |
FUEL FILTER | SE429B/4 | 1 | $76 | |
ALT BELT | 541/398 | 1 | $94 | |
FAN BELT | 541/419 | 5 | $160 | |
THERMOSTAT | SE573/1 | 2 | $671 | |
TOP COVER JOINT | SE478 | 12 | $5 | |
ROCKER CASE GASKET | SE152D/26 | 12 | $94 | |
B.Main warranty parts | ||||
Spare Parts Name | P/N (part number) | QTY | Unit Price(USD) | |
FRONT OIL SEAL | 554/126 | 1 | $163 | |
REAR OIL SEAL | 554/127 | 1 | $263 | |
MAIN BEARING | SEV574T | 7 | $394 | |
MAIN BEARING | SEV574U | 7 | $773 | |
MAIN BEARING | SEV574V | 7 | $1,394 | |
BIG END BEARING | SE91AA/3M | 12 | $140 | |
BIG END BEARING | SE91AA3M010 | 12 | $544 | |
BIG END BEARING | SE91AA3M020 | 12 | $628 | |
CONROD BOLT | 363/48 | 24 | $61 | |
CONROD BUSH | Y01/00023 | 12 | $366 | |
THRUST WASEHR | 262/151 | 2 | $560 | |
VALVE | SE7AJ/14 | 48 | $246 | |
GUIDE | 392/42 | 48 | $28 | |
INSERT INLET | 740/101 | 48 | $128 | |
INSERT INLET | 740/106 | 24 | $192 | |
SPRING | 365/472 | 48 | $24 | |
RETAINER | L7C/15 | 48 | $27 | |
RETAINER | SE1B/39 | 48 | $8 | |
KIT, PISTON | SE901BA | 12 | $1,227 | |
OIL COOLING JET | SE121A/50 | 1 | $40 | |
OIL COOLING JET | SEV121E/50 | 12 | $695 | |
KIT, PISTON RING | 359/552 | 12 | $392 | |
LINER | SE7E/2 | 12 | $339 | |
KIT, LINER RING | 576/167 | 24 | $59 | |
PUSHROD | SEV153 | 24 | $95 | |
PUSHROD | SEV153B | 12 | $249 | |
Spare Parts Name | P/N (part number) | QTY | Unit Price(USD) | |
COLLET | HW7B/18 | 96 | $7 | |
GASKET, CYL. HEAD | SE2H | 12 | $276 | |
KIT, REPAIR | SE145BC | 1 | $2,932 | |
PRIMING PUMP | 879/39 | 1 | $173 | |
TURBOCHARGER | SE652CN | 2 | $8,368 | |
SUMP GASKET | 12SE70A | 1 | $224 | |
WATER PUMP ASSY. | SE145AY | 1 | $4,070 | |
FUEL LIFT PUMP | SE597N | 1 | $1,944 | |
INJECTOR | R/858/12 | 12 | $2,108 | |
SLEEVE | SE1/12 | 12 | $87 | |
SEAL SLEEVE | 576/139 | 12 | $10 | |
NOZZLE | 726/66 | 12 | $669 | |
INJECTION WASHER | 277/124 | 12 | $7 | |
INJECTOR SEAL | 576/136 | 12 | $7 | |
INJECTOR SEAL | 576/137 | 12 | $7 | |
OIL COOLER | 582/139 | 1 | $9,073 | |
TUBESTACK | SE445E/2 | 1 | $1,351 | |
STARTER MOTOR | 701/137 | 2 | $1,395 | |
REALY | 589/93 | 2 | $232 | |
ALTERNATOR | 702/186 | 1 | $950 | |
SOLENOID | 589/91 | 1 | $1,250 |
