Sdec Engine Radiator Assy Cooling System Water Cooled Tank

Sdec Engine Radiator Assy Cooling System Water Cooled Tank

Quick Details:

Conditions
of Use:
Car Type, Trailer Type, Marine, Land Use
Usage: Emergency Crew, Standby Unit, Common Units
Output Type: AC Three Phase
Cooling
Method:
Water Cooling
Installation
Method:
Fixed
Generator
Type:
Diesel Generator
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
Radiator SC25 SC33
Material
Copper
Engine Speed
1500rpm/1800rpm
Frequency
50Hz/60Hz
Part Type
Brand New
Phase
Single or Three Phase
Output
400/230V 380/220V 440/220V 415/240V 480/277V
Quality Standard
ISO9001, ISO14001, CE
Delivey Time
5-20 Days
Delivery Way
by Shipping or by Airway
Transport Package
Plastic Seaworth Packing with Carton
Specification
1500x400x1800MM
Trademark
SDEC
Origin
China
HS Code
8708911000
Production Capacity
8000

Product Description

Sdec Engine Radiator Assy Cooling System Water Cooled Tank Sc15g500d2 Sc25g610d2 Sc25g690d2 Sc27g755D2 Sc27g830d2 Sc33W990d2 Sc33W1150d2Sdec Engine Radiator Assy Cooling System Water Cooled Tank Sc15g500d2 Sc25g610d2 Sc25g690d2 Sc27g755D2 Sc27g830d2 Sc33W990d2 Sc33W1150d2

WT-SC SHANGCHAI SERIES SPECIFICATION 50HZ @ 1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine Model cyl displacement Exhaust Gas Temp. Battery Vol. Max power Governor Open Type Dimension
Standby Power Prime Power Cons 100%(L/H)
KVA/KW KVA/KW L ºC V KW L×W×H(MM) Weight KG
WT-SC70 70/55 63/50 15.1 SC4H95D2 4L 4.3 600 24 68 Elec. 1980*880*1510 960
WT-SC88 88/70 80/64 19 SC4H115D2 4L 4.3 600 24 86 Elec. 1980*880*1510 1020
WT-SC110 110/88 100/80 25 SC4H160D2 4L 4.3 600 24 116 Elec. 2000*930*1580 1115
WT-SC125 125/100 113/90 25 SC4H160D2 4L 4.3 600 24 116 Elec. 2000*930*1580 1135
WT-SC138 138/110 125/100 28.6 SC4H180D2 4L 4.3 600 24 132 Elec. 2150*930*1580 1170
WT-SC165 165/132 150/120 36.5 SC7H230D2 6L 6.5 600 24 170 Elec. 2460*980*1690 1410
WT-SC175 175/140 160/128 35.7 SC8D220D2 6L 8.27 600 24 160 Elec. 2490*1080*1800 1610
WT-SC185 185/148 169/135 36.5 SC7H230D2 6L 6.5 600 24 170 Elec. 2460*980*1690 1490
WT-SC200 200/160 180/144 40.7 SC8D250D2 6L 8.27 600 24 185 Elec. 2490*1080*1800 1660
WT-SC206 206/165 188/150 39.9 SC7H250D2 6L 6.5 600 24 185 Elec. 2460*980*1690 1490
WT-SC220 220/176 200/160 45 SC8D280D2 6L 8.27 600 24 204 Elec. 2490*1080*1800 1770
WT-SC250 250/200 225/180 49.6 SC9D310D2 6L 8.82 600 24 228 Elec. 2600*1080*1800 1818
WT-SC275 275/220 250/200 54.1 SC9D340D2 6L 8.82 600 24 250 Elec. 2600*1080*1800 2028
WT-SC330 330/264 300/240 70.4 SC13G420D2 6L 12.88 600 24 308 Elec. 3040*1380*1880 2861
WT-SC344 344/275 313/250 70.4 SC13G420D2 6L 12.88 600 24 308 Elec. 3040*1380*1880 2941
WT-SC385 385/308 350/280 71.6 SC12E460D2 6L 11.8 600 24 338 Elec. 3230*1180*1750 2841
WT-SC413 413/330 375/300 81.2 SC15G500D2 6L 14.16 600 24 363 Elec. 3040*1380*1880 3069
WT-SC500 500/400 450/360 100.4 SC25G610D2 12V 25.8 650 24 445 Elec. 3630*1720*2230 4163
WT-SC550 550/440 500/400 113.1 SC25G690D2 12V 25.8 650 24 505 Elec. 3630*1720*2230 4271
WT-SC605 605/484 550/440 125.6 SC27G755D2 12V 26.6 650 24 555 Elec. 3630*1720*2230 4413
WT-SC620 620/496 563/450 125.6 SC27G755D2 12V 26.6 650 24 555 Elec. 3630*1720*2230 4413
WT-SC688 688/550 625/500 141 SC27G830D2 12V 26.6 650 24 610 Elec. 3630*1720*2230 4553
WT-SC825 825/660 750/600 174.9 SC33W990D2 6L 32.8 680 24 726 Elec. 4360*1620*2140 6296
WT-SC950 950/760 875/700 210 SC33W1150D2 6L 32.8 680 24 860 Elec. 4360*1620*2140 6296
WT-SC SHANGCHAI SERIES SPECIFICATION 60HZ @ 1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine Model cyl displacement Exhaust Gas Temp. Battery Vol. Max power Governor Open Type Dimension
Standby Power Prime Power Cons 100%(L/H)
KVA/KW KVA/KW L ºC V KW L×W×H(MM) Weight KG
WT-SC70 70/55 63/50 15.1 SC4H95D2 4L 4.3 600 24 68 Elec. 1980*880*1510 960
WT-SC88 88/70 80/64 19 SC4H115D2 4L 4.3 600 24 86 Elec. 1980*880*1510 1020
WT-SC110 110/88 100/80 25 SC4H160D2 4L 4.3 600 24 116 Elec. 2000*930*1580 1115
WT-SC125 125/100 113/90 25 SC4H160D2 4L 4.3 600 24 116 Elec. 2000*930*1580 1135
WT-SC138 138/110 125/100 28.6 SC4H180D2 4L 4.3 600 24 132 Elec. 2150*930*1580 1170
WT-SC165 165/132 150/120 36.5 SC7H230D2 6L 6.5 600 24 170 Elec. 2460*980*1690 1410
WT-SC175 175/140 160/128 35.7 SC8D220D2 6L 8.27 600 24 160 Elec. 2490*1080*1800 1610
WT-SC185 185/148 169/135 36.5 SC7H230D2 6L 6.5 600 24 170 Elec. 2460*980*1690 1490
WT-SC200 200/160 180/144 40.7 SC8D250D2 6L 8.27 600 24 185 Elec. 2490*1080*1800 1660
WT-SC206 206/165 188/150 39.9 SC7H250D2 6L 6.5 600 24 185 Elec. 2460*980*1690 1490
WT-SC220 220/176 200/160 45 SC8D280D2 6L 8.27 600 24 204 Elec. 2490*1080*1800 1770
WT-SC250 250/200 225/180 49.6 SC9D310D2 6L 8.82 600 24 228 Elec. 2600*1080*1800 1818
WT-SC275 275/220 250/200 54.1 SC9D340D2 6L 8.82 600 24 250 Elec. 2600*1080*1800 2028
WT-SC330 330/264 300/240 70.4 SC13G420D2 6L 12.88 600 24 308 Elec. 3040*1380*1880 2861
WT-SC344 344/275 313/250 70.4 SC13G420D2 6L 12.88 600 24 308 Elec. 3040*1380*1880 2941
WT-SC385 385/308 350/280 71.6 SC12E460D2 6L 11.8 600 24 338 Elec. 3230*1180*1750 2841
WT-SC413 413/330 375/300 81.2 SC15G500D2 6L 14.16 600 24 363 Elec. 3040*1380*1880 3069
WT-SC500 500/400 450/360 100.4 SC25G610D2 12V 25.8 650 24 445 Elec. 3630*1720*2230 4163
WT-SC550 550/440 500/400 113.1 SC25G690D2 12V 25.8 650 24 505 Elec. 3630*1720*2230 4271
WT-SC605 605/484 550/440 125.6 SC27G755D2 12V 26.6 650 24 555 Elec. 3630*1720*2230 4413
WT-SC620 620/496 563/450 125.6 SC27G755D2 12V 26.6 650 24 555 Elec. 3630*1720*2230 4413
WT-SC688 688/550 625/500 141 SC27G830D2 12V 26.6 650 24 610 Elec. 3630*1720*2230 4553
WT-SC825 825/660 750/600 174.9 SC33W990D2 6L 32.8 680 24 726 Elec. 4360*1620*2140 6296
WT-SC950 950/760 875/700 210 SC33W1150D2 6L 32.8 680 24 860 Elec. 4360*1620*2140 6296

Sdec Engine Radiator Assy Cooling System Water Cooled Tank Sc15g500d2 Sc25g610d2 Sc25g690d2 Sc27g755D2 Sc27g830d2 Sc33W990d2 Sc33W1150d2Sdec Engine Radiator Assy Cooling System Water Cooled Tank Sc15g500d2 Sc25g610d2 Sc25g690d2 Sc27g755D2 Sc27g830d2 Sc33W990d2 Sc33W1150d2Sdec Engine Radiator Assy Cooling System Water Cooled Tank Sc15g500d2 Sc25g610d2 Sc25g690d2 Sc27g755D2 Sc27g830d2 Sc33W990d2 Sc33W1150d2Sdec Engine Radiator Assy Cooling System Water Cooled Tank Sc15g500d2 Sc25g610d2 Sc25g690d2 Sc27g755D2 Sc27g830d2 Sc33W990d2 Sc33W1150d2Sdec Engine Radiator Assy Cooling System Water Cooled Tank Sc15g500d2 Sc25g610d2 Sc25g690d2 Sc27g755D2 Sc27g830d2 Sc33W990d2 Sc33W1150d2Sdec Engine Radiator Assy Cooling System Water Cooled Tank Sc15g500d2 Sc25g610d2 Sc25g690d2 Sc27g755D2 Sc27g830d2 Sc33W990d2 Sc33W1150d2FAQ1.What’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order, we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .WINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
