Sdec Sc33W1150d2 Shanghai Engine spare Part

Quick Details:

Conditions of Use:	Car Type, Trailer Type, Marine, Land Use
Usage:	Emergency Crew, Standby Unit, Common Units
Output Type:	AC Three Phase
Cooling Method:	Water Cooling
Installation Method:	Fixed
Generator Type:	Diesel Generator

Customization:	Available \| Customized Request

Send email to us

Product Detail

Product Tags

Basic Info.

Model NO.

SDEC SC33W1150D2

Engine Speed

1500rpm/1800rpm

Frequency

50Hz/60Hz

Aspiration Engine Typ

Turbocharged

Cooling System

Water Cooled

Governing Type

Electrical Starting GAC

Delivery

by Shipping or by Airway

Part Type

Brand New

Quality Standard

ISO9001, ISO14001, CE

Transport Package

Plastic Seaworth Packing with Carton

Specification

500x480x500MM

Trademark

SDEC

Origin

China

HS Code

850300

Production Capacity

8000

Product Description

SC33W1150D2 SDEC Shanghai Engine Spare Parts Maintenance List Repair Overhaul
500Hours Maintenance Spare Parts List
Item	Description	Part Number	Qty
Item	Description	Part Number	Qty	1	CARTRIDGE,LUB	W18A-003-01	3
2	FILTER,FUEL	W98A-001-01	2
3	CLEANER,AIR	S00021550	2


1000Hours Maintenance Spare Parts List

Item	Description	Part Number	Qty
Item	Description	Part Number	Qty	1	CARTRIDGE,LUB	W18A-003-01	3
2	FILTER,FUEL	W98A-001-01	2
3	CLEANER,AIR	S00021550	2
4	Front Crankshaft Seal	W02A-132-01	1
5	Rear Crankshaft Seal	W02A-133-01	1
6	Main Bearing (Upper)	S00010180	7
7	Main Bearing (Lower)	S00010280	7
8	Main Thrust Bearing	W02A-118-01	4
9	BEARING,CONNECTING ROD	W05A-112-01	12
10	The first piston ring	W05A-106-01	6
11	Second piston ring	S00022098	6
12	Oil ring assembly parts	S00022099	6
13	FAN BELT	W16B-114-02	1
14	Cylinder head cover oil seal ring	W04A-120-01	6
15	NOZZLE TIP	W28A-000-08	6
3000Hours Maintenance Spare Parts List

Item	Description	Part Number	Qty
Item	Description	Part Number	Qty	1	CARTRIDGE,LUB	W18A-003-01	3
2	FILTER,FUEL	W98A-001-01	2
3	CLEANER,AIR	S00021550	2
4	Front Crankshaft Seal	W02A-132-01	1
5	Rear Crankshaft Seal	W02A-133-01	1
6	Main Bearing (Upper)	S00010180	7
7	Main Bearing (Lower)	S00010280	7
8	Main Thrust Bearing	W02A-118-01	4
9	BEARING,CONNECTING ROD	W05A-112-01	12
10	The first piston ring	W05A-106-01	6
11	Second piston ring	S00022098	6
12	Oil ring assembly parts	S00022099	6
13	Intake tappet parts	W04B-005-01	6
14	exhaust tappet parts	W04B-006-01	6
15	Cam shaft front bearing	W02A-111-01	1
16	Cam shaft intermediate bearing	W02A-113-01	5
17	Cam shaft rear bearing	W02A-112-01	1
18	Cam shaft assembly	W09A-001-01	1
19	The connecting rod machining parts	W05A-001-01	6
20	THERMOSTAT	S00010360	3
21	PUMP,LUBRICATION OIL	W15A-001-01	1
22	PUMP,WATER	W20A-001-01	1
23	LINER,CYLINDER	W02A-102-01	6
24	Cylinder sealing ring	W02A-117-01	18
25	PISTON,ENGINE	W05A-101-01	6
26	PIN,PISTON	W05A-111-01	6
27	RING,RETAINING	B00001047	12
28	ORIFICE, PISTON COOLING JET	W02A-003-01	6
29	VALVE,INTAKE	W04B-101-01	12
30	VALVE,EXHAUST	W04B-102-01	12
31	SENSOR,SPEED	S00011410	1
32	FAN BELT	W16B-114-02	1
33	Cylinder head cover oil seal ring	W04A-120-01	6
34	Oil cooler	W02A-122-01	1
35	GASKET,CYLINDER HEAD	W02A-107-01	2
36	TURBOCHARGER	S00020937	1
37	TURBOCHARGER	S00020938	1
38	MOTOR,STARTING	W11A-001-01	1
39	ALTERNATOR	W11B-000-02	1
40	NOZZLE TIP	W28A-000-08	6
41	PUMP,FUEL INJECTOR	W28C-001-02	1
