Sdec Sc9d340d2 Shanghai Engine Part

Sdec Sc9d340d2 Shanghai Engine Part

Quick Details:

Conditions
of Use:
Car Type, Trailer Type, Marine, Land Use
Usage: Emergency Crew, Standby Unit, Common Units
Output Type: AC Three Phase
Cooling
Method:
Water Cooling
Installation
Method:
Fixed
Generator
Type:
Diesel Generator
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
SDEC SC9D340D2
Engine Speed
1500rpm/1800rpm
Frequency
50Hz/60Hz
Aspiration Engine Typ
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Delivery
by Shipping or by Airway
Part Type
Brand New
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Packing with Carton
Specification
500x480x500MM
Trademark
SDEC
Origin
China
HS Code
850300
Production Capacity
8000

Product Description

Sdec Sc9d340d2 Cyliner Gasket Filter Water Fuel Pump Piston Injector Thermostat Crankshaft Camshaft Generator Alternator Sensor Shanghai Engine Part

SC9D340D2 SDEC Shanghai Engine Spare Parts Maintenance List Repair Overhaul
500Hours Maintenance Spare Parts List
Item Description Part Number Qty
1 CARTRIDGE,LUB D17-002-02 1
2 FILTER,FUEL S00009060 1
3 CLEANER,AIR F/1402000022 1
1000Hours Maintenance Spare Parts List
Item Description Part Number Qty
1 CARTRIDGE,LUB D17-002-02 1
2 FILTER,FUEL S00009060 1
3 CLEANER,AIR F/1402000022 1
4 Front Crankshaft Seal D02B-104-02A 1
5 Rear Crankshaft Seal D02A-118-02B 1
6 BEARING,CRANKSHAFT THRUS(up) D02A-111-900 1
7 BEARING,CRANKSHAFT THRUS(low) D02A-323-900 1
8 BEARING,MAIN D02A-110-900 6
9 BEARING,MAIN D02A-112-900 6
10 BEARING,CONNECTING ROD(UP) D05-113-900 6
11 BEARING,CONNECTING ROD (LOW) D05-113-902 6
12 PISTON RING D05-107-900(S00019243) 6
13 PISTON RING D05-108-900(S00019244) 6
14 OIL RING D05-002-900(D05-002-34) 6
15 FAN BELT D16A-106-36 1
16 GASKET,VALVE COVER (D04-135-901)D04-337-901 1
17 NOZZLE TIP CDLLA 155 P779 6
3000Hours Maintenance Spare Parts List
Item Description Part Number Qty
1 CARTRIDGE,LUB D17-002-02 1
2 FILTER,FUEL S00009060 1
3 CLEANER,AIR F/1402000022 1
4 BEARING,CRANKSHAFT THRUS(up) D02A-111-900 1
5 BEARING,CRANKSHAFT THRUS(low) D02A-323-900 1
6 BEARING,MAIN D02A-110-900 6
7 BEARING,MAIN D02A-112-900 6
8 BEARING,CONNECTING ROD(UP) D05-113-900 6
9 BEARING,CONNECTING ROD (LOW) D05-113-902 6
10 PISTON RING D05-107-900 6
11 PISTON RING D05-108-900 6
12 OIL RING D05-002-900 6
13 TAPPET D04-127-30C 12
14 CAMSHAFT BUSHING D02A-113-01B 7
15 CAMSHAFT D09-101-900 1
16 ROD,ENGINE CONNECTING D05-001-901 6
17 TENSIONER ,BELT D16A-003-900 1
18 THERMOSTAT D22-102-900 1
19 PUMP,LUBRICATION OIL D15-000-900 1
20 PUMP,WATER S00020626 1
22 ROD,PUSH D04-128-900 12
23 LINER,CYLINDER D02A-104-900 6
24 PISTON,ENGINE S00007796 6
25 PIN,PISTON D05-112-40 6
26 RING,RETAINING B00001039 12
27 ORIFICE, PISTON COOLING JET D02A-030-900 6
28 VALVE,INTAKE D04-110-901 12
29 VALVE,EXHAUST D04-111-900 12
30 SENSOR,SPEED S00011542 1
31 FAN BELT D16A-106-36 1
32 GASKET,VALVE COVER D04-337-901 1
33 GASKET,OIL COOLER CORE D02A-133-900 1
34 WASHER,SEALING D18-105-900 1
35 GASKET,CYLINDER HEAD D02A-109-901 1
36 TURBOCHARGER S00008689 1
37 GASKET INJECTOR S00009757 6
38 MOTOR,STARTING S00022618 1
39 ALTERNATOR D11-102-23 1
40 FUEL INJECTOR S00009158 6
41 PUMP,FUEL INJECTOR S00004227 1
42 CORE,COOLER D18-001-900 1
43 VALVE STEM SEAL D04-105-900 24

Sdec Sc9d340d2 Cyliner Gasket Filter Water Fuel Pump Piston Injector Thermostat Crankshaft Camshaft Generator Alternator Sensor Shanghai Engine PartSdec Sc9d340d2 Cyliner Gasket Filter Water Fuel Pump Piston Injector Thermostat Crankshaft Camshaft Generator Alternator Sensor Shanghai Engine PartSdec Sc9d340d2 Cyliner Gasket Filter Water Fuel Pump Piston Injector Thermostat Crankshaft Camshaft Generator Alternator Sensor Shanghai Engine PartSdec Sc9d340d2 Cyliner Gasket Filter Water Fuel Pump Piston Injector Thermostat Crankshaft Camshaft Generator Alternator Sensor Shanghai Engine PartSdec Sc9d340d2 Cyliner Gasket Filter Water Fuel Pump Piston Injector Thermostat Crankshaft Camshaft Generator Alternator Sensor Shanghai Engine PartSdec Sc9d340d2 Cyliner Gasket Filter Water Fuel Pump Piston Injector Thermostat Crankshaft Camshaft Generator Alternator Sensor Shanghai Engine PartΔFAQ1.What’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .WINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.ΔFactory Inspection: the test items before delivery are mainly as follows:1.Each gensetsshall be put into commission and loading more than 1hours totally. They are tested on idleload, testing range 25% 50% 75% 100% 110% 75% 50% 25% 0%2.The noise level is tested by requested3.All of the meters on the control panel shall be testedThe appearance of the genset and all of the label and nameplate shall be checked
